Technical Parameter
Receiver:
- Carrier frequency range: 530MHZ – 580MHZ/ 615MHZ -665MHZ
- Oscillation mode: PLL
- Sensitivity: 5DBUV
- Balanced output (XLR outputjack): 250MV/ 600Ω
- Unbalanced output (1.4″ outputjack): 400MV/ K3Ω
- Operating voltage: DC 12-16V
- Operating current: < 350MA
Transmitter:
- RF power output: max 30MW
- Oscillation mode: PLL
- Transmit frequency stability: <30PPM
- Dynamic range: > 100DB (A)
- Frequency Response: 50HZ – 15KHZ
- Maximum input sound pressure: 130DB SPL
- Power: 2 * (1,5V) AA Alkaline Battery
